Silent Angel Munich M1
Silent Angel Munich M1 Music Network Streamer
Superior Hardware System
The M1 is born to pursue superior audio performance without any compromise.
- Elegant metal enclosure with a solid aluminum alloy front panel
- High-performance yet low-power CPU, 4-core 1.5GHz ARM Cortex-A72
- Substantial system memory for large streaming buffers and caches to run multiple applications simultaneously
- Advanced circuitry with high quality components
- Fan-less heat dissipation with a highly efficient heat-sink (~20˚C lower after applied)
- A highly permeable EMI absorber (>120 @1MHz) to reduce electrical interference
- Gold plated audio output ports (RCA L/R, 6.35mm headphone jack, and Coaxial & AES/EBU)
Specifications
| Available Color | Black |
| Power Consumption | 10W at max |
| Headphone Jack | 6.35 mm headphone jack x 1 33 Ohm
|
| Digital Outputs | AES/EBU port x 1 I2S port x 1* Coaxial port x 1 - Supports up to PCM 384KHz and DSD 5.6M (DSD128) * I2S output signal is not compatible with Holo Audio's DAC * I2S using HDMI cable, not support HDMI protocol. |
| USB Audio | USB Audio port x 1 - Supports up to PCM 768KHz and DSD 11.2M (DSD256) |
| Analog Output | RCA (L+R) - 2Vrms THD+N : 0.00134 / 0.00164% - Frequency response : 20Hz ~20KHz+- 0.5dB - SNR : 108dB |
| USB | USB 3.0 x 2 USB 2.0 x 1 - Above USB ports are for external storage |
| M-IO | M-IO x 1* *Reserved. To be enabled by future firmware upgrade |
| M-LINK | M-LINK x 1* *Reserved. To be enabled by future firmware upgrade |
| Ethernet | 1 GbE RJ45 x 1 |
| Music Format | AAC, M4A, MP3, OGG, FLAC, WAV, ALAC, DSD(DSF, DFF), WAV64, AIFF, CUE files, WMA, APE |
| Gapless Playback | Supported |
| MQA Handling | The M1 will transmit the signal to the DAC which supports MQA decoding. MQA is supported only by connecting to the USB-audio port. |
| LED Indicator | Mute LED x 1 Power LED x 1 Digital Output LED x 2* *Yellow light on when in DSD format / Green light on when in PCM format |
| Temperature | Operating: 32 ~ 86 °F Storage: -4 ~ 158 °F |
| Humidity | Operating: 10% ~ 90% RH (non-condensing) Storage: 5% ~ 95% RH (non-condensing) |
| Dimensions | 6.11(W) inch x 1.99(H) inch x 4.34(D) inch |
| Weight | 2.21 lbs |
