Silent Angel Bonn N8 Pro
Silent Angel Bonn N8 Pro
Bonn N8 Pro was created for music lovers who want to build a dedicated
“HiFi Ecosystem” and achieve the best possible audio quality. Silent
Angel’s rigorous approach preserves the integrity of the source and
delivers a high-purity signal to connected components, for a performance
unattainable with typical Network Switches. Purpose-engineered for High
Resolution Streaming Networks, Bonn N8 Pro provides the ideal
foundation for sonic excellence.
Unique and Advanced Designs
- Eight gold-plated Gigabit Ethernet Ports with spaced out ports to physically reduce possible signal interference.
- Class-leading Radar-Grade internal switching power supply module, which is exclusive to noise-sensitive acoustic equipment.
- Perfectly timed data transmission.
- TCXO (Temperature Compensation Crystal Oscillator) greatly lowers network latency issues and jitter effects.
Specifications
| Color | Black |
| Power Input | IEC (AC) 100-240V, 50/60Hz (DC) 12V/1A at max |
| Power Consumption | 10 Watt at max |
| Ethernet Port | Pure gold-plated 1GbE RJ45 port x 8 |
| Interface | Clock input switch x 1 (external/internal) - BNC interface 10MHz external Word Clock - Silent Angle specialized TCXO clock module LED indicator switch x 1 - Control the on/off status of LAN port LED Grounding Port x 1 - Connect to a ground box to make the signal quality more purer and precise without interference |
| LED Indicator | Power LED (Green) x 1 at the front panel Port Status LED x 8 (Light on when linked; Flash when it's active) at the rear panel) Green: 1000Mbps; Amber: 100Mbps |
| Temperature | Operating: 32 ~ 86 °F Storage: -4 ~ 158 °F |
| Humidity | Operating: 10% ~ 90% RH (non-condensing) Storage: 5% ~ 95% RH (non-condensing) |
| Dimensions | 17.37 (W) inch x 2.05 (H) inch x 6.89 (D) inch |
| Weight | 5.74 lbs |
