Denafrips Thallo 12th - Power amplifier
Denafrips Thallo 12th - Power amplifier
The THALLO our premium offering of stereo power amplifier. It is a beefed-up version of the award-winning HYPERION, fully discrete, true balanced, class AB power amplifier. The output power is rated at conservative 120W per channel into 8ohms, 220W into 4ohms (both channels driven, rms).
The 600VA toroid transformer is custom-made for audio with copper shielding. Total 36 pieces of large reservoir capacitors (200,400uF) and fast switching action schottky diodes, delivering more than adequate DC power rails to the modular power amplifier modules.
True balanced input are being amplified (both +ve and -ve signal w.r.t gnd) by the modular power amplifier circuitry. Each channel is equipped with 4 pairs of output power transistors.
SPECIFICATIONS
| Description | Parameters |
|---|---|
| Highlight | Class-AB, True Balanced, Fully Discrete Power Amp |
| Input | XLR |
| Input Impedance | 22k Ohms |
| Input Sensitivity | 1.8Vrms |
| Output | 4mm Speaker Binding Post |
| Gain | 26dB |
| Output Power | 100w RMS per channel into 8ohms |
| 150w RMS per channel into 4ohms | |
| AC Power Requirement | 100-240VAC, 50/60Hz (Worldwide Voltage) |
| Power Consumption | 0.5W (Standby), 35W (Idle), 365W (Operational) |
| Frequency Response | 10-80k（-2.2dB） |
| THD+N | <0.00125%（A） |
| S/N Ratio | ≥118dB（A） |
| Dynamic Range | >121dB |
| Stereo Crosstalk | -110dB |
| Dimension | 370×330×120 mm |
| Weight | 17 Kg |
| Color | Silver / Black |
2.223,14 €
2.223,14 €
-
