Canor Virtus M1 Vacuum Tube Power Amplifier

Product features

• Harmonic distortion - 0,0028 % at 1 W; 0,011 % at 5 W and 0,13 % at 50 W is achieved by harmonizing all circuits and components.

• The transformer core is vacuum impregnated, and the entire transformer is encapsulated in a special anti-vibration compound. In addition, the massive, welded cover in which the transformer is located, creates effective electromagnetic shielding and contributes significantly to the excellent signal-to-hum distance. The additional capacitor at the input improves the dynamic of the anode voltage filtration.

• The filtration capacity is 3.900 mF / 550 V. A choke, that is placed under a welded cover, has been used to eliminate anode voltage ripple, which increases the filtering efficiency of the 100 Hz component of the anode voltage.

• The output permalloy transformers are specially designed for the power amplifier.

• Only high-quality polypropylene capacitors are used in the signal path.

• The conductors on the signal paths consist of slow-drawn oxygen-free copper, which is coated with pure silver.

• instant switching between feedback and zero feedback.

Specifications
